Endress Hauser Clamp On Flow Meter Prosonic Flow: Portable Liquid Monitoring Guide
Quick Answer
Endress Hauser Prosonic Flow portable clamp on meters are widely used for temporary liquid measurement and flow surveys. If your application involves clean water, wastewater, cooling water, or low viscosity chemicals, Silver Instruments offers a cost effective portable clamp on ultrasonic flow meter with shorter lead times for Southeast Asia, Oceania, Latin America, Africa, and the Middle East. Send your pipe size in DN, pressure in bar, temperature in Celsius, and flow range to receive a quote.
What This Guide Covers
This Endress Hauser clamp on flow meter Prosonic Flow portable liquid monitoring guide compares key features, installation limits, and lower cost alternatives for field measurement. We focus on industrial users in Vietnam, Indonesia, Saudi Arabia, Nigeria, Chile, and Australia.
Why Portable Clamp On Flow Meters Are Used in Liquid Monitoring
Many plants run temporary flow surveys before buying permanent meters. A portable clamp on meter does not require pipe cutting or process shutdown. Technicians strap transducers on the outside of a pipe, enter the pipe material and wall thickness, and start measuring. Common tasks include pump performance testing, heat exchanger balancing, leak detection, and verification of installed flow meters.
Typical pipe sizes for portable clamp on meters range from DN15 to DN6000. Accuracy depends on pipe condition. The Endress Hauser Prosonic Flow portable units can reach plus or minus 0.5 to 1.0 percent of reading on clean pipes. On old or lined pipes, accuracy drops. Most engineers skip this part and then question the reading. We have seen this on customer sites many times.
Endress Hauser Prosonic Flow Portable Features That Matter
Endress Hauser Prosonic Flow portable meters support clamp on transducers for liquid applications. They work well on clean liquids and moderately dirty water. The meter has data logging, USB or Ethernet output, and battery operation for field use. Some configurations are rated for ATEX Zone 1 and Zone 2. Output options include 4-20 mA HART, RS485 Modbus, and pulse.
The device handles pipe materials like carbon steel, stainless steel, copper, PVC, and PE. Temperature range depends on transducer type, often from minus 40 to 200 degrees Celsius. For high temperature above 150 degrees Celsius, you may need high temperature transducers and longer installation time.
Where Endress Hauser Portable Meters Work Well
A desalination plant in Saudi Arabia used a Prosonic Flow portable meter to check flow distribution across reverse osmosis trains. A chemical plant in Vietnam measured sulfuric acid flow during a debottlenecking project. A food and beverage factory in Australia verified CIP water flow on stainless steel lines. These are common applications.
So, if your project specifies Endress Hauser, or the fluid is aggressive, high temperature, or the process cannot be disturbed, the Prosonic Flow is a safe choice.
Silver Instruments Portable Clamp On Alternative
Silver Instruments supplies a portable clamp on ultrasonic flow meter for liquid monitoring. The unit, model SUF-200P, is designed for clean water, wastewater, cooling water, seawater, and low viscosity chemicals. It measures pipe sizes from DN15 to DN1200. Accuracy is plus or minus 1.0 percent of reading. Repeatability is 0.2 percent. The meter includes a 4-20 mA output, RS485 Modbus, and a 512 MB data logger. Battery life is about 12 hours under continuous use.
Because we focus on industrial end users and distributors in Southeast Asia, Oceania, Latin America, Africa, and the Middle East, the price is often 30 to 50 percent lower than comparable Endress Hauser portable kits. Lead time is usually 5 to 10 working days for standard models. We have supplied a paint manufacturer in Indonesia and a water utility in Nigeria with portable units for flow surveys.
How to Choose Between Endress Hauser and Silver Instruments
If the process temperature exceeds 120 degrees Celsius, the liquid has high gas content, or the project requires brand certification, choose Endress Hauser. If you have a standard water or chemical line between DN50 and DN500, temperature from 5 to 80 degrees Celsius, and pressure below 16 bar, the Silver Instruments SUF-200P can handle the job.
Most customers ask for a quote first. Send us your pipe material, outside diameter, wall thickness, liquid type, flow range in cubic meters per hour, and desired output. We will reply with a model recommendation and a formal quotation within 24 hours.
Installation Tips for Portable Clamp On Flow Meters
Use a straight pipe run of at least 10 pipe diameters upstream and 5 pipe diameters downstream. Clean the pipe surface before mounting the transducers. Apply enough coupling compound. Enter the correct pipe wall thickness. If the pipe has thick scale or internal liner, the signal may fail. In practice, old galvanized steel pipes with heavy rust cause the most problems.
Do not install the sensors on the bottom of a horizontal pipe. Air bubbles collect there. Install on the side or top. For sewage or slurry, expect signal loss. A portable ultrasonic flow meter works best on liquids with low solids content.
FAQ
What pipe sizes can a clamp on flow meter measure?
Standard clamp on flow meters measure from DN15 to DN6000. The Silver Instruments SUF-200P covers DN15 to DN1200. Larger pipes need special transducers and longer delivery times.
Can the Endress Hauser Prosonic Flow portable unit measure seawater?
Yes. Seawater has good acoustic properties. Many desalination plants use clamp on meters for flow surveys. Silver Instruments also sells a seawater flow meter for desalination plant applications. Send your salinity and pipe details for a specific quote.
How long does the battery last on a portable clamp on meter?
The Endress Hauser Prosonic Flow portable unit typically runs 8 to 14 hours depending on backlight and logging intervals. The Silver Instruments SUF-200P runs about 12 hours. Both support external power banks for longer surveys.
What accuracy can I expect from Silver Instruments portable clamp on meter?
For a clean pipe with straight run, the SUF-200P delivers plus or minus 1.0 percent of reading. Repeatability is 0.2 percent. For DN50 to DN500 water lines, this is enough for pump tests and balancing work.
How fast can Silver Instruments ship to Vietnam or Saudi Arabia?
Standard portable clamp on meters ship within 5 to 10 working days. Express shipping to Vietnam, Saudi Arabia, Nigeria, Chile, and Australia takes 3 to 6 days by air. We pack the meter in a hard case with couplant, charger, cables, and a quick start guide.
Get a Quote
For a portable clamp on ultrasonic flow meter quote, send your pressure in bar, temperature in Celsius, pipe size in DN, and flow range. Contact Silver Automation Instruments today.
